Modeling and Simulation of Multibody Systems - Part II

About

This course aims at acquainting you with the modeling and simulation of constrained multibody systems, and especially mechanical systems with kinematic loops, such as real vehicle or bicycle suspensions, parallel manipulators or robots, musculoskeletal systems, etc.

You will also learn to deal with more advanced numerical analyses:
- Direct kinematics;
- Inverse kinematics;
- Equilibrium;
- Modal analysis;
- Direct Dynamics;
- Inverse Dynamics.

This course is based on (1) video clips focusing on the main theoretical background and concepts, (2) well-illustrated written sections given more details about the mathematical formulation, and (3) questions, exercises and modeling projects.

Despite the intrinsic complexity of such systems in terms of morphology and motions, basic skills in Newtonian mechanics, linear algebra and numerical methods are sufficient to model them, provided that the endless and tedious computation related to their internal kinematics and dynamics are at our disposal. This is the purpose of the symbolic program ROBOTRAN, which can be used with this course and can automatically generate the full set of equations of motion of a constrained MBS, in a symbolic manner, i.e. exactly as if you were writing them by hand, whatever the size and their morphological complexity of the application. Hence, this course will instead teach you how to intervene upstream and downstream this generation step.

Upstream the latter, you will learn how to translate a real system, e.g. a car suspension, into a virtual multibody model comprising algebraic constraints between joints, kinematic loops, etc.

Downstream the symbolic generation, your intervention will consist in:

- Completing the symbolic model with features that are specific for your system, e.g. a tire force model or the tuning of a motion controller, among other things;

- Selecting and implementing under the form of a program (in Python, Matlab, or C) the suitable numerical method to solve the differential equations of motion, given the original question; (1) an equilibrium solution can give you the static forces and the system deflection, (2) a time simulation can compute any transient motion of the system submitted to forces and torques, (3) a modal analysis will provide you with the eigenmodes that inform you about the system stability and damping characteristics, (4) an inverse dynamics study can provide you with the necessary forces and torques for any prescribed motion of the system, (5) etc.

- Selecting the most suitable results, including self-explanatory - and sometimes funny - video animations of your multibody system in motion.

In sum, this course, based on the use of the ROBOTRAN* symbolic generator, will allow you to focus on the most interesting aspects of the multibody modeling process, by entirely mastering your computer model from the input data to the results, instead of using a black-box multibody program that clearly goes against the educational objective of such a course.

Enjoy Multibody Dynamics!

*Note: The course was built to teach modeling and simulation of multibody systems, and not to teach any specific software. However, we suggest that you use the symbolic ROBOTRAN program to model and study the various multibody systems proposed in this course.

What you will learn

In this course devoted to constrained multibody systems, you will learn how to:

• formulate the user and loop constraints existing in your system;
• establish the equations of motion of constrained multibody systems using the coordinate partitioning method;
• build and master a program (in Python, Matlab or C) to simulate constrained multibody system;
• analyze your multibody system behavior thanks to the suitable numerical method (equilibrium, modal analysis, time integration, inverse models)

Skills you learn

• Morphology
• Mortgage-Backed Securities
• MATLAB
• Human Musculoskeletal Systems
• Kinematics
• C (Programming Language)
• Motion Control Systems
• Mechanical Systems
• Linear Algebra
• Simulations
• Basic Math
• Mechanics
• Suspension (Vehicle)
• Modal Analysis
• Python (Programming Language)
• Numerical Analysis
• Inverse Kinematics
• Computer Simulation
• Differential Equations
• Animations

Auto Summary

Explore advanced modeling and simulation techniques for multibody systems with "Modeling and Simulation of Multibody Systems - Part II." This expert-level course, offered by edX, delves into complex systems such as vehicle suspensions, robots, and musculoskeletal frameworks. Over 22 hours, you'll master numerical analyses and joint constraints. Available with Professional and Starter subscriptions, this course is perfect for seasoned professionals in science and engineering seeking to deepen their expertise.
